L1D4 - TCS N Drop in Decoder - Life-Like & Walthers Proto
TCSTCS L1D4 DECODER
The L1D4 is a N-scale drop-in decoder which has been designed for Life Like and Walthers Proto locomotives. Examples include the following:
Life Like:
- GP20
- GP60
Walthers (Proto):
- GP20
- GP38-2
See the installation pages for a full list of compatible engines!
Note: The L1D4 has copper tabs installed which slip over the motor contacts on the locomotive.
- Back EMF Load Compensation:
Provides superior slow speed control and high performance under load.
- Quiet Drive:
Super-quiet motor control for "buzz" free motor performance.
- DC Mode:
Decoder will automatically detect DC power. You can also configure how your lighting effects function on DC.
- RailCom®:
This feature allows the decoder to talk to the command station. RailCom supports expansion for new features.
- Variable Momentum:
Allows you to make custom acceleration and deceleration curves.
- LED Support:
This product does not require external resistors when connecting LED's.
- Function Remapping:
Buttons 0 through 12 may be used to control the lighting functions of this decoder.
- Programmable Lighting Effects:
Choose from 20 separate user-programmable lighting effects!
- Dimmable Brightness:
Configure multiple different brightness levels for your LED's or incandescent bulbs.
- Decoder Lock:
Feature which prevents accidental/unwanted programming while activated.
- Airwire™ Compatible:
Fully compatible with Airwire™ operation.
- User-Loadable Speed Tables:
Configure custom speed curves and set speed limits.
